Simple Operating Gas Fired Steam Boiler Residential Total Weight Around 24 ton

Name: Simple Operating Gas Fired Steam Boiler Residential Total Weight Around 24 ton
Brand: YONGXING
Price: 1 USD

Brand Name : YONGXING

Model Number : WNS1ton~20ton,1.25/1.6/2.5Mpa,Oil fired steam boiler

Certification : ISO9001,ISO14001,A-CLASS，SGS,BV

Place of Origin : HENAN PROVINCE

MOQ : 1set

Price : negotiable

Payment Terms : T/T,L/C,Western Union

Supply Ability : 1000SETS/MONTH

Delivery Time : 15-30DAYS

Packaging Details : Nude packing+wooden box+steel box ,and etc.

PRESSURE : 0 or 10bar,16bar,25bar

Burner : Italy Riello Or Italy Baltur, and brand Olin

Boiler capacity : 1Ton~20tons

Boiler outer package : Stainless Steel

Features : Corrugated Furnace

Thermal Efficiency : 92.4%--94.5%

control mode : Automation

The return trip : Three return

Structure : Smoke Pipe

Material : Q345R Steel Plate

Working Life : More Than 20 Years

Protection : Interlock Alarm

Applications : Central heating, mass heating

Capacity : 4 tons of steam

water pump : LEO vertical stainless steel water pump

Usage : Industrial,hospital chemical industry school,Steam Outputing

Condition : New

Style : Horizontal

Fuel : Gas-fired,natural gas,lpg,lng

Output : Steam

Contact Now

Simple Operating procedure WNS10-1.25-YQ 10 ton gas fired steam boilers residential total weight around 24ton

gas fired steam boilers residential Description

Our company has more than 50 years of production experience and has formed the production capacity of more than 200 varieties of 9 series including 9000 steam tons of power station boilers, industrial boilers, pressure vessels and power plant boilers. Users provide a large number of high quality, efficient and energy efficient boiler products.

1. Gas fired steam boilers residential consists of the boiler main unit, the soot, and the piping system. The main engine and the soot part have been manufactured in the factory. The pipeline valves and instruments supported by the main machine have been randomly installed and transported to the site to host and The soot can be assembled.

2. Test the vehicle by connecting the air source, power supply and water pipeline on site. The installation cycle is greatly shortened and the product quality is guaranteed.

3. Joint control method using mechatronics control equipment and programmable logic controller (PLC). The advanced programmable logic controller (PLC) is the "central processor" of the control system. The control system is operated by the touch screen to make the boiler automatic control and reliable operation.

4. Scientific product design, advanced processing technology, strict quality control, and the continuous operation life of all boiler equipment produced by our factory is more than 10 years. The radiant heating surface of the boiler is a full corrugated furnace, and the convection heating surface adopts a threaded tobacco tube. The heating surface is large, the boiler produces heat and the heat efficiency is as high as 92% or more, which is higher than the national regulations.

gas fired steam boilers residential technical datasheet

Model	Output	Pressure	Temperature	Fuel	Temperature
Model	(t/h)	(Mpa)	(ºC)	Fuel	(ºC)
WNS0.5-0.7/1.0/1.25-YQ	0.5	0.7/1.0/1.25	170/184/194	heavy oil/light oil, natural gas/LPG/city gas	20
WNS0.7-0.7/1.0/1.25-YQ	0.7	0.7/1.0/1.25	170/184/194		20
WNS0.8-0.7/1.0/1.25-YQ	0.8	0.7/1.0/1.25	170/184/194		20
WNS1-0.7/1.0/1.25-YQ	1	0.7/1.0/1.25	170/184/194		20
WNS1.5-0.7/1.0/1.25-YQ	1.5	0.7/1.0/1.25	170/184/194		20
WNS2-1.0/1.25/1.6-YQ	2	1.0/1.25/1.6	184/194/204		20
WNS3-1.0/1.25/1.6-YQ	3	1.0/1.25/1.6	184/194/204		20
WNS4-1.0/1.25/1.6-YQ	4	1.0/1.25/1.6	184/194/204		20
WNS5-1.0/1.25/1.6-YQ	5	1.0/1.25/1.6	184/194/204		20
WNS6-1.0/1.25/1.6-YQ	6	1.0/1.25/1.6	184/194/204		20
WNS8-1.25/1.6-YQ	8	1.25/1.6	194/204		20
WNS10-1.25/1.6-YQ	10	1.25/1.6	194/204		20
WNS12-1.25/1.6-YQ	12	1.25/1.6	194/204		20
WNS15-1.25/1.6-YQ	15	1.25/1.6	194/204		20
WNS20-1.25/1.6-YQ	20	1.25/1.6	194/204		20
